Application - Orangeries

Stylish Architecture for Very Special Events

Typical uses:

Two Orangeries Providing Different Approaches

The Orangerie is HR-Structures’ most striking event structure yet.
It combines classic event building technology with large, glazed façades and the striking raised roof. Clean lines and bright, open space creates the ideal environment for larger events.

The modular structure is available in various spans and comes in Skyline Orangerie (ESO) and F-Series Orangerie (EFO) design variants.

Both variants are based on a self-supporting roof canopy structure with an 18° roof pitch and a characteristic roof height of 1.34m. The building is structurally designed to accommodate suspended loads and can be combined with heavy-duty or cassette flooring.

The aluminium structure can be powder-coated in custom RAL colours. A range of materials is available for roof and wall surfaces from Polyglas roof sheeting to translucent or solid variants.

Skyline Orangerie (ESO)

The ESO variant is the architecturally superior design featuring an external Skyline façade system.

Version	Skyline Orangerie
Profile	300 x 122mm
Width	15m / 20m / 25m
Side height	Up to 4.4m
Wall cladding	Skyline façade in front of the posts or PVC cladding
Gable cladding	PVC cladding or fixed façade up to the ridge
Suspended loads	90kg/m 1,000kg per point
Additional features	Optional ventilation along the 1m high roof ridge

F-Series Orangery (EFO)

The EFO variant is the more cost-effective version with classic integration of the wall elements between the posts.

Version	F-Series Orangerie
Profile	225 x 101mm
Width	15m / 20m
Side height	Up to 3m
Wall cladding	Skyline façade between the posts or PVC cladding
Gable cladding	PVC cladding only
Suspended loads	70kg/m 750kg per point

Get In Touch

Event Structures

First Name

Surname

Email address

Phone Number

Company Name

City of Event Location

Use case

Width

Length

Height

Other details

Consent

I agree that my details from the contact form will be collected and stored to answer my query. Note: You can revoke your consent at any time by email. You can find detailed information about how we handle user data in our data protection declaration.

Find out more about our Finance solutions

At HR-Structures, we know that cashflow matters. Investing in a new building or structure can be a major decision, which is why we work with Systems Finance to help make the process more accessible.

Event Project Case Studies

Our Solutions in Action

Innovative Structure Extension with Glass Façade and Premium Interior Finish

Width:

10m

Length:

25m

Height:

3.3m

Size:

250m²

This extension to an existing Event Vegas Structure was designed specifically for trade fairs and event purposes for our client Mäss support i Sverige AB.

Custom-Made Event Structure for Exclusive Events in Sweden

Width:

15m

Length:

15m

Height:

Size:

225m²

One of our recent projects is this premium event structure, designed and manufactured specifically for functions and events hosted by our client Partyhyra Ulricehamn AB.

Prestigious Event Structure for Large-Scale Events in Fiskum

Width:

15m

Length:

40m

Height:

Size:

600m²

This premium Skyline-Tent New York was designed for large-scale functions and representative events for our client Utleiepartner AS.

Flexible event structures for unforgettable events in Sweden

Width:

10m

Length:

20m

Height:

Size:

200m²

For our client Extrem Event i Östersund AB, we supplied several temporary event structures, including a Skyline Event Structure New York and three additional “Weinheim” tents.

Stunning Skyline Structures At The 24 Hours Of Le Mans

Width:

20m

Length:

30m

Height:

Size:

600m²

For the legendary 24 Hours of Le Mans endurance race, we worked with our partner iEvent to create two modular Skyline structures.

Sports Pavilion In India

Width:

35m

Length:

35m

Height:

7.5m

Size:

1225m²

Installed at a cricket ground in India, our 35m x 35m pavilion provides shaded seating for an integrated gallery and spacious terrace.
